Illinois Quick Facts
- Illinois is the fifth-largest energy-consuming state in the nation, and its industrial sector, which includes petroleum refining, coal mining, and agriculture, uses the most energy of any end-use sector in the state.
- Illinois ranks fourth in the nation in crude oil refining capacity behind Texas, Louisiana, and California, with a refining capacity of nearly 1 million barrels per calendar day.
- The estimated recoverable coal reserves in Illinois are the second-largest in the nation after Montana, and the state's coal mines account for 6% of U.S. total coal production.
- Illinois is the third-largest ethanol-producing state (1.5 billion gallons annually) and the fourth-largest biodiesel fuel producer (134 million gallons).
- Illinois generates more electricity from nuclear energy than any other state, and it accounted for about 12% of U.S. nuclear power generation in 2021.
Last Updated: July 21, 2022
Data
Last Update: March 16, 2023 | Next Update: April 20, 2023
Prices | |||||
---|---|---|---|---|---|
Petroleum | Illinois | U.S. Average | Period | find more | |
Domestic Crude Oil First Purchase | $ 73.66 /barrel | $ 76.45 /barrel | Dec-22 | ||
Natural Gas | Illinois | U.S. Average | Period | find more | |
City Gate | $ 6.81 /thousand cu ft | $ 7.68 /thousand cu ft | Dec-22 | find more | |
Residential | $ 12.23 /thousand cu ft | $ 14.75 /thousand cu ft | Dec-22 | find more | |
Coal | Illinois | U.S. Average | Period | find more | |
Average Sales Price | $ 31.15 /short ton | $ 36.50 /short ton | 2021 | ||
Delivered to Electric Power Sector | $ 1.88 /million Btu | $ 2.65 /million Btu | Dec-22 | ||
Electricity | Illinois | U.S. Average | Period | find more | |
Residential | 16.19 cents/kWh | 14.96 cents/kWh | Dec-22 | find more | |
Commercial | 11.54 cents/kWh | 12.42 cents/kWh | Dec-22 | find more | |
Industrial | 9.00 cents/kWh | 8.63 cents/kWh | Dec-22 | find more |
Reserves | |||||
---|---|---|---|---|---|
Reserves | Illinois | Share of U.S. | Period | find more | |
Crude Oil (as of Dec. 31) | -- | -- | 2021 | find more | |
Expected Future Production of Dry Natural Gas (as of Dec. 31) | -- | -- | 2021 | find more | |
Expected Future Production of Natural Gas Plant Liquids | -- | -- | 2021 | find more | |
Recoverable Coal at Producing Mines | 1,873 million short tons | 15.2% | 2021 | find more | |
Rotary Rigs & Wells | Illinois | Share of U.S. | Period | find more | |
Natural Gas Producing Wells | NA | NA | 2020 | find more | |
Capacity | Illinois | Share of U.S. | Period | ||
Crude Oil Refinery Capacity (as of Jan. 1) | 1,040,065 barrels/calendar day | 5.8% | 2022 | ||
Electric Power Industry Net Summer Capacity | 44,228 MW | 3.8% | Dec-22 |
Supply & Distribution | |||||
---|---|---|---|---|---|
Production | Illinois | Share of U.S. | Period | find more | |
Total Energy | 2,160 trillion Btu | 2.3% | 2020 | find more | |
Crude Oil | 18 thousand barrels per day | 0.1% | Dec-22 | find more | |
Natural Gas - Marketed | 2,131 million cu ft | * | 2021 | find more | |
Coal | 36,614 thousand short tons | 6.3% | 2021 | find more | |
Total Utility-Scale Net Electricity Generation | Illinois | Share of U.S. | Period | find more | |
Total Net Electricity Generation | 16,822 thousand MWh | 4.6% | Dec-22 | ||
Utility-Scale Net Electricity Generation (share of total) | Illinois | U.S. Average | Period | ||
Petroleum-Fired | NM | 1.0 % | Dec-22 | find more | |
Natural Gas-Fired | 11.8 % | 38.8 % | Dec-22 | find more | |
Coal-Fired | 21.7 % | 20.1 % | Dec-22 | find more | |
Nuclear | 52.6 % | 19.0 % | Dec-22 | find more | |
Renewables | 13.3 % | 20.4 % | Dec-22 | ||
Stocks | Illinois | Share of U.S. | Period | find more | |
Motor Gasoline (Excludes Pipelines) | 34 thousand barrels | 0.3% | Dec-22 | ||
Distillate Fuel Oil (Excludes Pipelines) | 2,659 thousand barrels | 3.0% | Dec-22 | find more | |
Natural Gas in Underground Storage | 917,793 million cu ft | 12.4% | Dec-22 | find more | |
Petroleum Stocks at Electric Power Producers | NM | NM | Dec-22 | find more | |
Coal Stocks at Electric Power Producers | 2,995 thousand tons | 3.3% | Dec-22 | find more | |
Fueling Stations | Illinois | Share of U.S. | Period | ||
Motor Gasoline | 3,804 stations | 3.4% | 2019 | ||
Propane | 85 stations | 3.1% | 2022 | ||
Electricity | 1,328 stations | 2.5% | 2022 | ||
E85 | 293 stations | 6.6% | 2022 | ||
Compressed Natural Gas and Other Alternative Fuels | 149 stations | 4.5% | 2022 |
Consumption & Expenditures | |||||
---|---|---|---|---|---|
Summary | Illinois | U.S. Rank | Period | ||
Total Consumption | 3,613 trillion Btu | 5 | 2020 | find more | |
Total Consumption per Capita | 283 million Btu | 25 | 2020 | find more | |
Total Expenditures | $ 34,115 million | 7 | 2020 | find more | |
Total Expenditures per Capita | $ 2,668 | 45 | 2020 | find more | |
by End-Use Sector | Illinois | Share of U.S. | Period | ||
Consumption | |||||
» Residential | 940 trillion Btu | 4.6% | 2020 | find more | |
» Commercial | 740 trillion Btu | 4.4% | 2020 | find more | |
» Industrial | 1,131 trillion Btu | 3.6% | 2020 | find more | |
» Transportation | 803 trillion Btu | 3.3% | 2020 | find more | |
Expenditures | |||||
» Residential | $ 9,583 million | 3.7% | 2020 | find more | |
» Commercial | $ 5,985 million | 3.4% | 2020 | find more | |
» Industrial | $ 5,477 million | 3.3% | 2020 | find more | |
» Transportation | $ 13,070 million | 3.2% | 2020 | find more | |
by Source | Illinois | Share of U.S. | Period | ||
Consumption | |||||
» Petroleum | 211 million barrels | 3.2% | 2020 | find more | |
» Natural Gas | 1,060 billion cu ft | 3.5% | 2021 | find more | |
» Coal | 29 million short tons | 5.3% | 2021 | find more | |
Expenditures | |||||
» Petroleum | $ 15,615 million | 3.1% | 2020 | find more | |
» Natural Gas | $ 8,571 million | 4.5% | 2021 | find more | |
» Coal | $ 982 million | 4.2% | 2021 | find more | |
Consumption for Electricity Generation | Illinois | Share of U.S. | Period | find more | |
Petroleum | NM | NM | Dec-22 | find more | |
Natural Gas | 16,475 million cu ft | 1.6% | Dec-22 | find more | |
Coal | 2,156 thousand short tons | 5.2% | Dec-22 | find more | |
Energy Source Used for Home Heating (share of households) | Illinois | U.S. Average | Period | ||
Natural Gas | 75.4 % | 46.5 % | 2021 | ||
Fuel Oil | 0.1 % | 4.1 % | 2021 | ||
Electricity | 18.4 % | 41.0 % | 2021 | ||
Propane | 4.4 % | 5.0 % | 2021 | ||
Other/None | 1.8 % | 3.5 % | 2021 |
Environment | |||||
---|---|---|---|---|---|
Renewable Energy Capacity | Illinois | Share of U.S. | Period | find more | |
Total Renewable Energy Electricity Net Summer Capacity | 8,064 MW | 2.6% | Dec-22 | ||
Ethanol Plant Nameplate Capacity | 1,743 million gal/year | 10.0% | 2022 | ||
Renewable Energy Production | Illinois | Share of U.S. | Period | find more | |
Utility-Scale Hydroelectric Net Electricity Generation | 8 thousand MWh | * | Dec-22 | ||
Utility-Scale Solar, Wind, and Geothermal Net Electricity Generation | 2,204 thousand MWh | 4.6% | Dec-22 | ||
Utility-Scale Biomass Net Electricity Generation | 32 thousand MWh | 0.7% | Dec-22 | ||
Small-Scale Solar Photovoltaic Generation | 54 thousand MWh | 1.5% | Dec-22 | ||
Fuel Ethanol Production | 33,807 thousand barrels | 10.2% | 2020 | ||
Renewable Energy Consumption | Illinois | U.S. Rank | Period | find more | |
Renewable Energy Consumption as a Share of State Total | 8.2 % | 32 | 2020 | ||
Fuel Ethanol Consumption | 9,481 thousand barrels | 9 | 2020 | ||
Total Emissions | Illinois | Share of U.S. | Period | find more | |
Carbon Dioxide | 203.4 million metric tons | 3.9% | 2019 | ||
Electric Power Industry Emissions | Illinois | Share of U.S. | Period | find more | |
Carbon Dioxide | 57,167 thousand metric tons | 3.5% | 2021 | ||
Sulfur Dioxide | 55 thousand metric tons | 4.7% | 2021 | ||
Nitrogen Oxide | 31 thousand metric tons | 2.5% | 2021 |
Analysis
Last Updated: July 21, 2022
Overview
Located in the center of the United States, Illinois is the most populous Midwestern state, and ranks sixth in the nation in population and fifth in GDP.1,2 The state's population is concentrated in a few large urban areas, leaving much of the state rural.3 Chicago, located in northeastern Illinois on the shores of Lake Michigan, is home to one-fifth of the state's population and is the third-largest U.S. city.4,5
Illinois plays an important role in the nation's economy because of its central location and extensive transportation network. The state has the nation's fourth-busiest commercial airport and the second-largest rail network with almost 7,000 route miles.6,7 Illinois has the third-largest number of interstate highways, after California and Texas, at almost 2,200 miles, and it also has about 1,100 miles of navigable waterways. The state's inland waterway system connects the Great Lakes to the Mississippi River and the Ohio River, linking the central United States to the Atlantic Ocean and the Gulf of Mexico.8
Illinois is a key hub for crude oil and natural gas moving throughout the United States.
Illinois is a key hub for crude oil and natural gas moving throughout the United States.9 The state is a major electricity generator and has the largest number of nuclear power plants in the nation, as well as the only chemical facility that converts uranium yellowcake into uranium hexafluoride, a step in making nuclear fuel.10,11,12,13 Illinois also has substantial coal reserves and some crude oil resources as well.14,15 The state ranks fifth in the United States in wind-powered electricity generating capacity.16 Illinois has about 27 million acres of farmland and ranks among the top 10 states in the market value of agricultural products sold.17,18 Corn and soybeans, the state's most important crops, provide feed for livestock and are used as feedstock for many ethanol and biodiesel plants.19,20,21,22
Illinois is the nation's fifth-largest energy-producing and energy-consuming state. The state's largest end-use energy-consuming sector is industry, which includes agriculture, and accounts for 30% of the state total.23,24 Chemicals, food and beverage, and machinery manufacturing are the largest contributors to the state's manufacturing GDP. Other energy-intensive industries in Illinois include petroleum refining, coal mining, and primary metal manufacturing.25 The transportation sector accounts for one-fourth of the state's energy consumption, the residential sector accounts for slightly less than one-fourth, and the commercial sector uses one-fifth. Despite the state's cold winters and its warm, humid, and occasionally hot summers, Illinois' total energy consumption per capita ranks at the midpoint of the states.26,27
Electricity
Illinois is the nation's fifth-largest electricity producer, and typically sends about one-fifth of the power it generates to other states over interstate transmission lines.28,29 Two regional grid systems serve Illinois: the PJM Interconnection and Midcontinent Independent System Operator (MISO).30 The PJM Interconnection is a regional transmission organization that manages the movement of wholesale electricity between the northern portion of the state, including the major urban areas around Chicago, and the Mid-Atlantic region.31,32 MISO controls the flow of electricity for the rest of the state and also serves much of the middle of the nation from Louisiana to Canada.33,34
Illinois generates more electricity from nuclear energy than any other state, accounting for one-eighth of the nation’s total nuclear power generation.
Illinois generates more electricity from nuclear energy than any other state, accounting for one-eighth of the nation's total nuclear power generation.35 In 2021, the state's 6 nuclear power plants, with 11 total reactors, produced 53% of the state's electricity net generation.36,37 All the nuclear plants rank among the 10 largest power plants in the state by annual electricity generation, and 5 of the 6 are among the 10 largest by capacity.38 Because of economic issues in the electricity market, several of the state's nuclear power stations were scheduled to close, but the Illinois legislature in late 2016 approved financial incentives to keep the stations operating. The utility that owns two nuclear power plants in northern Illinois, the Byron and Dresden generating facilities, reversed its plans to retire the nuclear power plants in the fall of 2021 after a new state law passed that requires Illinois to transition to 50% clean energy by 2040 and 100% clean energy by 2050.39,40,41,42,43
Coal-fired power plants have been the second-largest electricity providers in Illinois since 2009 However, coal's contribution to in-state generation declined significantly from 45% of electricity net generation in 2011 to 24% in 2021, as nearly 5,400 megawatts of coal-fired generating capacity shut down during that period. Additional coal-fired power plants with almost 3,000 megawatts of capacity are scheduled to close in 2022 and 2023 in response to stricter emissions regulations and economic pressures.44,45,46 The state's natural gas-fired generation reached a record high in 2020, but declined in 2021 after natural gas prices rose and more competitively priced coal-fired generation increased. Natural gas-fired generation provided almost 12% of Illinois' electricity net generation in 2021, nearly four times more than in 2011. Renewables, led by wind energy, accounted for almost all the rest of the state's net generation.47,48
About 95% of Illinois households use electric air conditioning, but only one in six Illinois households rely on electricity for home heating.49,50 Electricity retail sales in Illinois do not vary greatly among end-use sectors. The residential and commercial sectors each account for 35% of the state's electricity retail sales, and the industrial sector accounts for most of the remaining 30%. A small amount of electricity sales go the transportation sector. 51
Coal
Illinois’s estimated recoverable coal reserves are the second-largest in the nation.
Illinois has about 15% of the nation's economically recoverable coal reserves, second only to Montana, and it is the nation's fourth-largest coal producer after Wyoming, West Virginia, and Pennsylvania.52,53 In 1673, Europeans first discovered coal in North America along the Illinois River, and coal underlies about two-thirds of the state. However, coal was not mined in the state until the 1800s.54,55 Currently, coal mines in Illinois provide about 6% of U.S. total coal production.56
Illinois exported about one-fifth of the coal it produced to other countries in 2020.57 Typically, 15 states received Illinois coal primarily to generate electricity, with Kentucky, and Florida receiving the most coal.58 Illinois produces only bituminous coal, which has a high sulfur content and burns for a long time. Many electric utilities burn that coal in combination with lower sulfur coal from other regions to be able to meet federal Clean Air Act emissions regulations.59,60,61 Coal from Illinois is transported to other states mainly by rail and barge.62 Illinois consumes about one-fourth of the coal mined in the state, primarily in the electric power sector, and trucks or conveyors move much of that coal.63,64 Nearly all of the coal that Illinois receives from other states comes from Wyoming by rail and is used for electric power generation.65 Industrial and coking plants account for one-sixth of the state's coal consumption.66
Petroleum
Illinois has the fourth-largest crude oil-refining capacity of any state.
Illinois is a major crude oil-refining state. Its four refineries can collectively process up to 1 million barrels of crude oil per calendar day into petroleum products, the largest refining capacity in the Midwest and the fourth-largest in the nation after Texas, Louisiana, and California.67 However, the state's crude oil reserves and production are modest.68,69 Almost all of the producing wells in Illinois are located in the southern half of the state, in the Illinois Basin.70 Oil exploration in Illinois began in the 1860s, but commercial production did not occur until 1905. Since the 1860s, tens of thousands of wells have been drilled in the state. Crude oil production in Illinois peaked in 1940, reaching almost 150 million barrels that year. In 2021, the state's oil production decreased to just over 7 million barrels, the lowest output level since the mid-1930s.71,72 Most of the oil wells in the state are stripper wells that each produce less than 2 barrels of crude oil per day.73
Several crude oil and petroleum product pipelines cross Illinois and the state is home to the Patoka Terminal crude oil storage hub, which is the second-largest pipeline terminal in the Midwest and has a storage capacity of more than 19 million barrels.74,75,76 Illinois has crude oil ports at Chicago on Lake Michigan and at Peoria on the Illinois Waterway, which connects Lake Michigan to the Mississippi River. Chicago's port also handles petroleum product imports.77 The largest refinery in the state is the Wood River refinery, in the southwest near St. Louis, Missouri.78 There is another refinery in southern Illinois and two more in northeastern Illinois. The state's refineries process domestic crude oil, as well as Canadian and other imported crude oils, into motor gasoline, diesel fuel, jet fuel, and other petroleum products.79,80
Illinois consumes the sixth-most petroleum of any state. The transportation sector accounts for 70% of Illinois' petroleum consumption, and almost half the petroleum used in the state is motor gasoline.81,82 Reformulated motor gasoline blended with ethanol, which reduces smog-forming emissions, is required to be sold in the areas around Chicago in northeastern Illinois and around St. Louis, Missouri, in southwestern Illinois.83 There are 312 public fueling stations throughout the state that sell E85, a blend of 85% ethanol and 15% gasoline. Only Minnesota and Iowa have more E85 refueling stations.84 Illinois is a busy aviation hub and nearly one-tenth of petroleum used in the state is jet fuel, making it the fifth-largest consumer of jet fuel among the states.85,86 One-fourth of the petroleum consumed in Illinois is used in the industrial sector, the state's second-largest petroleum-consuming sector.87 The industrial sector also uses about two-thirds of the hydrocarbon gas liquids (HGLs), including propane, ethane, and ethylene, consumed in Illinois.88 Farmers use propane to dry the state's corn crop after harvest, and industry uses ethane and ethylene as feedstock for making plastics.89,90,91,92 Overall, Illinois is the third-largest HGL-consuming state and HGLs account for about one-eighth of the state's petroleum consumption.93,94 Only a small amount of petroleum is used in the commercial sector and in the residential sector, where about 4 in 100 households use petroleum products, mostly propane, for home heating.95,96
Natural gas
Illinois has more than one-tenth of total U.S. natural gas underground storage capacity.
Illinois has no significant natural gas reserves and few producing natural gas wells.97,98,99 However, the state is a major natural gas crossroads, with many interstate natural gas pipelines and two natural gas market centers.100 Natural gas supplies enter Illinois primarily from Iowa, Missouri, and Indiana. Almost three-fifths of the natural gas that enters Illinois continues on to the east and north through Indiana and Wisconsin.101 Illinois has 28 underground natural gas storage fields with a total storage capacity of just over 1 trillion cubic feet of natural gas, which is slightly more than one-tenth of U.S. total natural gas underground storage capacity.102
Illinois is the eighth-largest natural gas-consuming state in the nation.103 In 2021, the residential sector used 35% of all natural gas delivered to consumers in the state, the largest share of any sector.104 Almost 8 in 10 Illinois households use natural gas for heating.105 The industrial sector was the second-largest natural gas-consuming sector in Illinois, using 24% of the natural gas delivered in the state. The state's electric power sector accounted for 20% of natural gas use, consuming a record amount of natural gas. The commercial sector also made up 20% of the state's natural gas use.106
Renewable energy
Illinois's primary renewable energy product is biofuels. The state is a leading producer of both ethanol and biodiesel, with an annual production capacity of 1.7 billion gallons of ethanol and 174 million gallons of biodiesel. A fertile prairie state, Illinois is a major corn and soybean producer. The state's 12 ethanol plants use corn as feedstock, and the state's 5 biodiesel plants use multiple feedstocks, including soy and corn oils.107,108,109,110 The state is the third-largest ethanol producer, after Iowa and Nebraska, and is the ninth-largest consumer of ethanol in the nation.111,112 The state is the fourth-largest biodiesel producer and the third-largest consumer of biodiesel, after Texas and California.113,114
In 2021, Illinois ranked fifth in the nation in wind power capacity with about 6,900 megawatts installed.
In 2021, renewable energy, including small-scale, customer-sited solar panel systems (less than 1 megawatt in capacity each) accounted for 11% of Illinois' in-state electricity generation, almost triple the amount generated a decade earlier. Wind is the primary renewable resource used for electric power generation in the state. In 2021, wind provided 90% of the state's renewable energy generation, and Illinois was fifth in the nation in utility-scale (1 megawatt or greater) wind capacity, with about 6,900 megawatts online.115,116 Illinois' best wind energy resources are found in the northern one-third of the state. About 1,200 megawatts of additional wind power capacity are either under construction or in advanced development.117,118
Solar energy, biomass, and hydropower generated 10% of Illinois' renewable-sourced electricity. In 2021, the state's total solar power generation was almost triple the level from the year before. The state's largest solar power facility, the 200-megawatt Prairie Solar Farm, came online in late 2021. An additional 1,700 megawatts of solar power capacity are scheduled to come online through 2024. Nearly two-thirds of the state's solar generation in 2021 came from customer-sited, small-scale generation, mostly from rooftop solar panels.119,120 Waste and methane gas from municipal landfills fuel nearly all of the state's biomass electricity generation at 13 facilities with 73 megawatts of combined generating capacity121,122 Illinois has many rivers, but the state's relatively level terrain limits hydroelectric potential. The state's 8 hydroelectric facilities have a total of 33 megawatts of generating capacity.123,124
Illinois has a renewable portfolio standard (RPS) that requires all investor-owned electric utilities and alternative retail electricity suppliers to obtain increasing proportions of their retail power sales from renewably-sourced generation. In 2021, the RPS target was increased to require that 50% of electricity retail sales come from renewable sources by 2040, replacing the earlier target of 25% by 2026.125,126 In 2007, Illinois also created an energy efficiency portfolio standard, requiring investor-owned electric and natural gas utilities and retail energy suppliers to achieve long-term reductions in their customers' electricity and natural gas use through efficiency measures.127
